4 Stacker & Reclaimer in an ore deposite
Baoshan Iron & Steel Co., Ltd.
MaJiShan Port, [CN]
8 Motorized Cable Reels [Program 7100]
Fibre optic rotary joints at the control drum
Modular assembly system - the cable reel can be upgraded after installation by adding drive units.
Magnetic Coupler Drive (MAG Drive) or Variable Frequency Drive (SMART Drive)
5 year or 15,000 hour operation before any maintenance is required - gearboxes are grease-lubricated from the factory.
Optimal corrosion protection to handle aggressive environments - flanges and reel drum are manufactured from hot dip galvanized steel or stainless steel.
- AC motor with magnetic coupler (MAG drive): up to 100 m/min
- Variable frequency controlled (SMART Drive): up to 180 m/min
Winding length: 700 m max
OD of spool:
- Monospiral spool: 1,100 mm - 8,000 mm
- 3-2-3 spool: 1,100 mm - 8,000 mm
- Type BNA: 1,100 Nm - 19,000 Nm
- Type X07: 1,100 Nm - 11,000 Nm
Slip ring assembly:
- Power low voltage max: 690 V - 1,600 A
- Power high voltage max: 24,000 V - 500 A
- Control max: 500 V - 25 A
- Data: fiber optic, mA
Temperature range: -40 °C - +60 °C
